2026 Trek Checkpoint+ SL 5 - Matte Bronze Age/Dark Web
Buy the New 2026 Trek Checkpoint+ SL 5 electric gravel bike for sale in South Africa at Biket — the official Trek Bikes online store. Lightweight carbon e-gravel bike built for endurance, speed, and long-distance adventure with powerful pedal-assist performance. Order online today with fast free nationwide delivery in South Africa.
OVERVIEW
The Checkpoint+ SL 5 is an electric gravel bike built to take you the distance. You get a TQ HPR60 motor with a smooth and quiet boost up to 28 mph (25 kph in Europe) and a 360 Wh battery that keeps going on your biggest rides. It comes ready to roll with an OCLV Carbon frame, durable alloy wheels, 12-speed Shimano GRX 1x shifting and endurance geometry to keep you comfortable for the long haul.
*Bags and Accessories in last image sold separate.
SPECS
*Please note – spec applies to all sizes unless listed separately
- Frame
-
500 Series OCLV Carbon, TQ drive system, tapered head tube, IsoSpeed, internal routing, flat-mount disc, mudguard mounts, UDH, 142x12 mm chamfered thru axle
- Fork
-
Checkpoint full carbon, tapered carbon steerer, mudguard mounts, triple rack mounts, flat-mount disc, 12x100 mm chamfered thru axle
- Weight
- ML - 13.81 kg / 30.45 lbs (with TLR sealant, no tubes)
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
- Battery
-
TQ 360Wh
- Charger
-
TQ 4A charger
- Controller
-
TQ color LED display with Bluetooth & ANT+ connectivity
- Motor
-
TQ-HPR60, 60 Nm, 300 watt maximum continuous rated power, 350 watt peak power
- Shifter
-
Shimano GRX RX820, 12-speed
- Rear derailleur
-
Shimano GRX RX822, 51T max cog
- *Crank
-
Size: XS, S
Praxis Alloy, 165 mm lengthSize: M, ML
Praxis Alloy, 170 mm lengthSize: L, XL
Praxis Alloy, 172.5 mm length - *Cassette
-
Size: XS, S, M, ML, L, XL
Shimano XT M8200, 10-51, 12-speedSize: XS, S, M, ML, L, XL
Shimano XT M8100, 10-51, 12-speed - Chain
-
Shimano XT M8100, 12-speed
- Max. chainring size
- 1x: 44T
- Wheel front
-
Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle
- Wheel rear
-
Bontrager Paradigm Comp 25, Tubeless-Ready, 25 mm rim width, SRAM XD-R 12-speed freehub, 142x12 thru axle
- Skewer front
-
Bontrager Switch chamfered thru axle
- Skewer rear
-
Bontrager Switch chamfered thru axle, removable lever
- Tyre
-
Bontrager Girona Pro, Tubeless Ready, GR puncture protection, aramid bead, 60 tpi, 700x42 mm
- Tyre part
-
Bontrager TLR sealant, 180 ml/6 oz
- Rim strip
-
Bontrager TLR
- Max tyre size
- 50 mm without mudguards, 42 mm with mudguards (as measured, see manual for details)
- Saddle
-
Verse Short Comp, steel rails, 145 mm width
- Seatpost
-
Bontrager carbon, 27.2 mm, 8 mm offset, 330 mm length
- *Handlebar
-
Size: XS, S
Bontrager Elite Gravel, alloy, 40 cm widthSize: M, ML
Bontrager Elite Gravel, alloy, 42 cm widthSize: L
Bontrager Elite Gravel, alloy, 44 cm widthSize: XL
Bontrager Elite Gravel, alloy, 46 cm width - Handlebar tape
-
Bontrager Supertack Perf tape
- *Stem
-
Size: XS
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm lengthSize: S, M
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm lengthSize: ML, L
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90mm lengthSize: XL
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100mm length - Brake rotor
-
Shimano CL800, CentreLock, 160 mm
- Brake lever
-
Shimano GRX RX820, 12-speed
- Rotor size
- Max brake rotor sizes: 180 mm front and rear
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
