2026 Trek Checkmate SLR 9 AXS - Era White/Buff Beige
The 2026 Trek Checkmate SLR 9 AXS represents the pinnacle of Trek’s gravel engineering. Built on the ultra light, ultra stiff SLR carbon chassis, this bike is designed for maximum speed, precision handling and all day efficiency on the most demanding gravel courses. Its advanced carbon layup smooths vibration while maintaining explosive responsiveness, giving you race winning control on rough terrain.
Equipped with SRAM’s flagship AXS wireless drivetrain, shifting is instantaneous and flawless under load, allowing you to focus fully on the ride. Premium carbon wheels, race level components and a fully integrated cockpit complete a setup worthy of elite gravel racers and high performance endurance riders.
Whether you’re chasing podiums, powering through high pace group rides or exploring long backcountry routes, the Checkmate SLR 9 AXS delivers uncompromising performance, stability and comfort. This is Trek’s fastest and most refined gravel platform ever.
Backed by the confidence of purchasing from an approved online Trek store.
OVERVIEW
The Checkmate SLR 9 AXS is our fastest and lightest gravel race bike, built to chase podiums down rowdy roads. It combines a lightweight aero design with IsoSpeed road-smoothing tech and new Gravel Race geometry that keeps you poised for the attack without eating up your energy. To keep you at the front of the pack, it's equipped with top-tier parts, like carbon wheels and SRAM's latest ergonomic RED AXS XPLR wireless drivetrain.
SPECS
*Please note – spec applies to all sizes unless listed separately
- Frame
-
800 Series OCLV Carbon, IsoSpeed, hidden mudguard mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat-mount disc, integrated chainkeeper, removable FD hanger, UDH, 142x12 mm chamfered thru axle
- Fork
-
Checkmate SLR full carbon, tapered carbon steerer, hidden mudguard mounts, flat-mount disc, 12x100 mm thru axle
- Weight
- ML – 7.55 kg/16.65 lb (with TLR sealant, no tubes)
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
- Battery
-
SRAM AXS battery pack (with charger)
- Shifter
-
SRAM RED AXS E1
- Rear derailleur
-
SRAM RED XPLR eTap AXS, 46T max cog
- *Crank
-
Size: XS, S
SRAM RED XPLR, power meter, 42T, DUB wide, 165 mm lengthSize: M
SRAM RED XPLR, power meter, 42T, DUB wide, 170mm lengthSize: ML, L
SRAM RED XPLR, power meter, 42T, DUB wide, 172.5 mm lengthSize: XL
SRAM RED XPLR, power meter, 42T, DUB wide, 175 mm length - *Bottom bracket
-
Size: XS, S, M, ML, L, XL
SRAM DUB, T47 threaded, internal bearingSize: XS, S, M, ML, L, XL
SRAM DUB Wide, T47 threaded, internal bearing - Cassette
-
SRAM XG-1391, 10-46T, 13-speed
- Chain
-
SRAM RED E1, 12/13-speed
- Max. chainring size
- See service manual
- Wheel front
-
Bontrager Aeolus RSL 37V, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 100 x 12mm thru axle
- Wheel rear
-
Bontrager Aeolus RSL 37V, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 142 x 12mm thru axle
- Skewer front
-
Bontrager Switch chamfered thru axle
- Skewer rear
-
Bontrager Switch chamfered thru axle, removable lever
- Tyre
-
Bontrager Girona RSL GR, Tubeless-Ready, aramid bead, 220 tpi, 700x38 mm
- Tyre part
-
Bontrager TLR sealant, 180 ml/6 oz
- Rim strip
-
Bontrager TLR
- Max tyre size
- 45 mm without mudguards, 38 mm with mudguards (as measured, see manual for details)
- *Saddle
-
Size: XS, S
Aeolus RSL, carbon rails, 155 mm widthSize: M, ML, L, XL
Aeolus RSL, carbon rails, 145 mm width - Seatpost
-
KVF aero carbon seat post, 5 mm offset, 280 mm length
- *Handlebar/stem (integrated)
-
Size: XS
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 37 cm control width, 40 cm drop width, 70 mm stem lengthSize: S
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 80 mm stem lengthSize: M
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 90 mm stem lengthSize: ML, L
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm drop width, 100 mm stem lengthSize: XL
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm drop width, 110 mm stem length - Handlebar tape
-
Trek EcoTack
- Brake rotor
-
SRAM Paceline X, rounded, CentreLock, 160 mm
- Rotor size
- Max brake rotor sizes: 180 mm front and rear
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
